Mini Slitting Line
The simple slitting line is an economical, reliable and practical coil slitting device. It is generally suitable for small processing factories or hardware stores.
Product Introduction
1. Introduction From Reliance （Xiamen）Industry Co.，Ltd
The simple slitting line is an economical, reliable and practical coil slitting device. It is generally suitable for small processing factories or hardware stores. The speed is not as fast as the professional slitting line, but in the case of ensuring the accuracy, the slitting effect can still be perfect, and it can be said that the cost is low and the effect is good.
2. Specifications/Technical parameters
Material Request | Material: 0.4mm Minimum Thickness, 1.5 mm Maximum Thickness Feeding width: 1250mm Ex Cold Rolled Coil, Galvanized Coil, PPGI, PPGL Yield strength: 245~550MPa |
Straightening, slitting and shearing machine | Polythene Film-On device, un-powered Feeding Section with guide device Two stages of powered shafts to guiding the sheet in and out Straightening Device with 4 over 3 shafts to remove the Coil-set Straightening motor: 11KW One stage of slitting rollers required Total four sets of slitting tools, Max five trips at one time Extra one set of slitting wheels used as spare parts The below picture about the slitting rollers for your reference only The min. slitting width between two pieces of tools is 70mm The min. slitting width at edge is 40mm Electric guillotine, Main Motor=3KW Working width: MAX.1250mm; work thickness: 0.4-1.5mm Protection Mesh Cover Above Roll-former To Avoid Hands Go Inside |
Slitting parameter | Feeding Section with guide device |
PLC control system | Control the quantity & cutting length automatically Combined with: PLC, Touch Screen(Siemens), Inverter (Schneider), Encoder (Omron), etc Cut-to-length tolerance≤±2 mm Control voltage 24V |
Table | un-powered, 6 meter long |
3. Product detail
1. Application: household appliance, hardware, auto industry, roll forming industry.
2. Original: Xiamen, China
3. Certification: ISO9001, CE etc.
4. Price: Negotiable
5. Voltage: 380V 50Hz, the voltage can be as local demand
6. Payment term: TT, LC
7. Delivery date: Negotiable
8. Packing: Naked package with poly wood case for control box
9. Market: ASEAN/Middle East/ South Asia/North America/Russia
10. Warranty: 1 year
4. Certificates
5. Our factory
Our factory was established in 2014, which covers an area of MORE THAN 10,000 SQUARE METERS. With 20 YEARS PROFESSIONAL EXPERIENCE, Meanwhile, we are the main drafter standard of China Non-standard roll former manufacturer and exporter of high quality roll forming machines in China. We are an ISO9001 approved company, and have European CE certification
6. Advantage
1. According to your demands, we may tailor equipment requirements, spray paint color, brand accessories replacement, and material selection.
2. The steel used in the equipment is standard steel from leading manufacturers, ensuring that the equipment has a longer service life.
3 The equipment setup is simple to select.
4 Prompt delivery
7. FAQ
1. How can I fix a problem with my equipment while I'm using it?
Please send us an email with images or a short video of the problem, and we will investigate and resolve it. If a part is broken during the warranty term, we will replace it for free.
2. Do you have the machines on hand?
No, it isn't. All roll forming machine, will be made according to your request.
3. How long will it take for your machine to arrive?
In average, our machine takes around 30 days to deliver; however, customized machines will be supplied after consultation with our clients.
