Floor Deck Roll Forming Machine
Floor Deck Roll Forming Machine provides the profiled metal plate as the permanent supporting formwork and works together with the cast-in-place reinforced concrete structure layer to form the permanent composite structure of the building. It is customarily called structural floor deck.
Product Introduction
1. Introduction
Floor Deck Roll Forming Machine has the characteristics of light weight, high strength, large bearing capacity and good seismic performance. The product can realize rapid production and high production quality. The machine has low noise and vibration. The finished product is compact in texture, accurate in size and smooth in appearance. The equipment has advanced technology, simple operation method and high working efficiency. Each machine is checked at all levels to ensure that a product delivered to customers meets international standards. We should supply products with higher precision and hardness according to customers' requirements.
Floor Deck Roll Forming Machine has a very intelligent master computer system, which can well analyze the input drawings, so as to produce according to the drawings, and the patterns and shapes of the plates produced are consistent with the drawings. The machine has the characteristics of high strength, high degree of automation and durability. The machine has good processing performance, can improve the surface accuracy of materials and improve the fatigue resistance of parts. We always put customers first, so if you have any questions, please feel free to ask us.
2. Specifications/Technical parameters
|
5Ton*1250mm Hydraulic un-coiler（ADVANCE MODE）
|
Hydraulic system to expand coil inner hole；Pump motor：4KW； Frequency Inverter to regulate turn speed；Motor：4KW Coil Inner-diameter=508±30mm. Coil Outer-diameter Max. 1200mm； Taper wedge expanding system Load Capacity: Max. 5 Tons; Coil Width Max. 1250mm； Automatic stopping device with limited switch as assistance to control stop/start rotation Self-contained electric controller, out of control system of the complete line
|
|
Floor Deck Roll Forming Machine |
Feeding section with guide Gear/Sprocket driving, 24-step to form, wall plate frame design Rollers material 40Cr Steel, CNC lathes, fine polished, hard Chrome Coated Shafts material 45# Steel, Diameter ф95mm, Precision Machined, fine Polished Main motor =18.5KW×2, Frequency speed control Max. Line speed of roll former：Approx. 18m/min
|
|
PLC Control System |
Control the quantity, drawing length automatically Combined with: PLC, Touch Screen (Siemens), Inverter (Schneider), Encoder (Omron), etc Cut-to-length tolerance≤±2.0 mm Control voltage 24V |
3. Product detail
1. Application: cement floor, tall building floors etc
2. Original: Xiamen, China
3. Certification: ISO9001, CE etc.
4. Price: Negotiable
5. Voltage: 380V 50Hz, the voltage can be as local demand
6. Payment term: TT, LC
7. Delivery date: Negotiable
8. Packing: Naked package with poly wood case for control box
9. Market: ASEAN/Middle East/ South Asia/North America/Russia
10. Warranty: 1 year
4. Certificates
5. EXHIBITIONS/MEETINGS
6. Direct Contact Information
Why choose us?
- Our Roof Sheet Making Machines are of superior quality and at competitive prices.
- We promote our own business development towards internationalization and proactively adapt to the trend of global economic integration.
- We’re committed to providing the highest quality Roof Sheet Making Machine products and services to our clients.
- The company strives for its permanent pursuit to meet the needs of its customers and to re-innovate its brilliance.
- Our Roof Sheet Making Machine products are designed to perform at the highest levels of efficiency and reliability.
- The production process used by our company is as advanced as that used in any other countries.
- Our factory has extensive experience in manufacturing Roof Sheet Making Machines that are of the highest quality.
- We are proud of the superior customer gratification and wide acceptance due to our persistent pursuit of top of the range both of those on merchandise and service for Floor Deck Roll Forming Machine.
- We provide excellent service and support to our customers, ensuring that they receive the best possible Roof Sheet Making Machine products.
- Our corporate culture is customer first, teamwork, continuous improvement, hard work and result orientation.
