High Speed Precision Slitting Line
The main process flow of High Speed Precision Slitting Line is as follows: feeding trolley feeding--upper uncoiler uncoiling-discharge rack--uncoiling storage pit--circular shearing machine slitting--waste edge mechanism--transition frame ---Tension mechanism--winder-unloading trolley--hydraulic parts--electrical control system--pneumatic parts.
Product Introduction
1. Introduction From Reliance （Xiamen）Industry Co.，Ltd
The main process flow of High Speed Precision Slitting Line is as follows: feeding trolley feeding--upper uncoiler uncoiling-discharge rack--uncoiling storage pit--circular shearing machine slitting--waste edge mechanism--transition frame ---Tension mechanism--winder-unloading trolley--hydraulic parts--electrical control system--pneumatic parts. The slitting line is also called slitting unit, slitting machine, slitting machine, and scissors. It cuts the metal coils into strips of various widths required, and then collects the strips into small rolls for the next process. It is a necessary equipment for precision cutting of the transformer, motor industry and other metal strips. Generally speaking, slitting lines are non-standard products, which are designed and manufactured according to customer requirements.
2. Specifications/Technical parameters
Technical information | INPUT: A steel coil slitting machine OUT PUT: Total power: about 200KW. |
Machine parts in the working line | 1. coil car 2. decoiler 3. shear cutter 4. pinch roll 5. coil guide 6. Slitting machine 7. scrap winder (both sides) 8. Loop table 9. separator and tension table 10. Deflector roll and exit threading table 11. Recoiler 12. Over arm separator in the recoiler. 13. Exit coil car for recoiler |
Slitting parameter | ●Type : Round knife cutting. ●Structure : Fabricated Steel, 42CrMo steel slitter arbor ●slitter arbor : diameter 180mm x 2 ●Vertical adjustment :Motorizes anti-backlash worm gear for Vertical adjustment ●Slitter Stand locking : Motorizes ●Gear box: ●Construction: : Fully enclosed helical gears, shaft rotate in roller bearings, and coupling to the motor. ●Motor : 55KW from Siemens ●Lubricant : Oil bath |
Control System | Standard Application Modules Reliance machinery Automation has years of experience in designing systems for metal slitting lines – both new machines and retrofits. We’ve taken this experience and developed standard application modules; these modules are field-proven, so you get the advantages of reduced engineering and start-up time. Yet we’ve included the ability to customize these modules for your machine control logic and options. Each option includes the software, hardware and drawings to implement this function.
Available Modules: _ Slitting Line Master- This module is required for each line and is the master for the slitting line. It includes software and hardware for control of the recoiler and operator. Functions include: _ Line start/stop _ Line speed adjust _ Line fast stop _ Line E-stop/reset _ Recoiler jog fwd/rev _ Recoiler mandrel expand/hold/collapse _ Uncoiler Control –to control a mechanical brake on the uncoiler. Functions include: _ Uncoiler tension set _ Uncoiler jog fwd/rev _ Uncoiler over/under _ Uncoiler mandrel expand/hold/collapse _ Hold-down roll raise/lower _ Uncoiler thread table raise/lower Slitter Control – There are a variety of options available to control a variable speed drive on the slitter. Functions include: _ Slitter load/loop adjust _ Slitter jog fwd/rev _ Looping pit raise/lower _ Tight/loop select Drives and Motors Metal slitting lines can be powered by AC We have available a wide choice of features and configurations available to fit each application and environment. The machine will be included the following accessories from supplier in main shipment ●The Blades : 20 pieces blades from the supplier ●Spacer: supply from the supplier ●Separator and disc from the supplier ●Oil and air pipes from the supplier. ●Wire from the supplier. ●3 Electrical control table from the supplier |
3. Product detail
1. Application: household appliance, hardware, auto industry, roll forming industry.
2. Original: Xiamen, China
3. Certification: ISO9001, CE etc.
4. Price: Negotiable
5. Voltage: 380V 50Hz, the voltage can be as local demand
6. Payment term: TT, LC
7. Delivery date: Negotiable
8. Packing: Naked package with poly wood case for control box
9. Market: ASEAN/Middle East/ South Asia/North America/Russia
10. Warranty: 1 year
