Corrugated Roll Forming Machine

Corrugated Roll Forming Machine for corrugated plates. This forming machine can directly discharge, shape and cut rolled strips at one time.

Product Introduction

1. Introduction

Corrugated Roll Forming Machine is widely praised for its direct discharge and one-time molding. The machine can automatically cut rolled strip with smooth and flat cutting surface. The machine is easy to operate, and the operator only needs to monitor the operation of the machine, thus greatly improving the production effect. The corrugated cardboard produced by this machine has wavy shape and strong structure, which occupies a large market space in housing construction. Adhering to the people-oriented concept, we can produce suitable machines according to customer requirements.


Corrugated paper is a kind of construction material with a wide range of applications, and Corrugated Roll Forming Machine is used to produce this material. The machine can be produced in batches according to the shape of the drawing, and the corrugated paper produced by the machine has the same thickness, size and appearance. The machine can automatically feed and cut, thus saving a lot of labor costs. We continue to develop new technologies to optimize products to help you improve production efficiency.



2. Specifications/Technical parameters

5Ton*1000mm Hydraulic un-coiler



Hydraulic system expand coil inner hole, Pump motor: 3KW

Frequency Inverter to regulate turning speed, Motor: 3KW

Taper-wedge expanding system

Load capacity = Max.5Tons

Coil Inner-diameter=510±30mm, Coil width = Max.1000mm

Automatic stopping device with limited switch as assistance to control stop/star rotation





Entry roller & Manual Pre-shearing device

Smart cut control, to cut off the end of the final piece of sheet only

Working thickness up to 0.8mm

Corrugated Roll Forming Machine



Feeding section with guide;

Gear/Sprocket driving;20-step to form;

Rollers manufactured from 45# Steel, CNC lathes, hard Chrome Coated

Shafts Diameter=ф75/95mm, Precision Machined

Main motor =7.5 KW, Frequency speed control

Max. Liner speed of roll former:Approx. 18-20m/min;

Hydraulic Cutting Device



Stop to cut, Post cut, No Blanking cut

Cutting tool material : Cr12, Heat treatment;mould steel with quenched treatment

Hydraulic unit, Pump motor =4.0KW (Hydraulic tank located inside)

PLC Control System

Combined with: PLC, Touch Screen (Siemens), Inverter (Schneider), Encoder (Omron), etc

Cut-to-length tolerance≤±2 mm

Control voltage 24V

Portable manual controller, FW/REV/STOP/EMERGENCY only

Foldable Product Rack

Un-powered, 3 units
